ALD-IPEPS: A platform independent KVM over IP gateway

supporting USB, digital video, audio, virtual media and power control, contained within a palm-sized unit

AdderLink iPEPS product is part of Adder's 'IPEPS' (IP Engine per Server) concept that delivers a complete, secure, non-blocking approach to computer management.

A powerful and flexible Digital KVM over IP product contained within a palm sized unit, AdderLink iPEPS DVI enables computer access from anywhere in the world, securely and remotely via the Internet or corporate network.

AdderLink iPEPS DVI uses Real VNC client software that is specifically designed for secure, high performance KVM over IP applications and supports both IPV4 and IPV6 addresses.

AdderLink iPEPS DVI can accept video signals from computers equipped with DVI, DisplayPort DP++ (Dual-Mode) or HDMI along with USB for mouse/keyboard control and for virtual media.

Digital Video Inputs
Adderlink iPEPS DVI accepts any single link DVI input up to 1920x1200 resolution. It can also be attached to computers with DisplayPort DP++ (Dual-Mode) or HDMI with adapter-cables enabling access to any computer with a digital video interface.

Independent Operation
AdderLink iPEPS DVI gives full control even during boot up, BIOS level or computer crash states, it will even work even if the controlled devices are not operational.

High Video Performance
AdderLink iPEPS DVI can be accessed by a standard web browser but for superior graphical performance, a Real VNC viewer should be used. Free of the limitations of HTTPS, Real VNC greatly enhances video performance.

Highly Secure; Support for IPV6 Addresses
Employing enterprise grade security (using AES 128 bit encryption and RSA 2048 bit public key authentication) as standard, AdderLink iPEPS DVI is further enhanced by the use of Real VNC that allows for the creation of ciphered user communications. Supports both IPV4 and IPV6 addreses.

USB and Virtual Media Support
To transfer files from remote users to controlled computers, AdderLink iPEPS DVI has been engineered to act as a conduit through which data can be passed. Files can be transferred via IP onto AdderLink iPEPS DVI and onto the target computer by means of a USB virtual media port.

Power Control through RS232 Serial Interface
AdderLink iPEPS DVI has an RS232 port to allow communication to devices like power switches, allowing remote rebooting of the target computer.

Choice of Power Source
AdderLink iPEPS DVI can either be powered from two USB cables or independently from an external 5V power source.

User Management
AdderLink iPEPS DVI can create up to 16 user profiles with defined access rights. The unit can be accessed by up to 4 users at any one time.

Remote Gateway to AdderLink Infinity
AdderLink iPEPS DVI can be used as a remote gateway into the Adderlink Infinity system by connecting it into an AdderLink Infinity reciever unit. This will allow users to access any computer on the Adderlink Infinity network with their normal username and passwords from any location including mobile devices.

In the Box
• iPEPS DVI module
• Power adapter plus country specific power cable [PSU-IEC-5VDC-2.5A]
• Rack chassis faceplate [X-RMK-FASCIA]
• 4x self-adhesive rubber feet
• CD-ROM
• DVI-D video cable M-M (2m) [VSCD1]
• 3.5mm jack stereo audio cable [VSC22]
• 2x USB Type-A to Type-B cables (2m) [VSC24]
• Power control cable [VSC45]
