![CL1308NUKIT CL1308NUKIT](images/CL1308N_P.jpg)
19-inch LCD KVM console w/ built-in 8-port multi-platform USB/PS2 KVM switch
with illuminated keyboard and 8x integrated VGA/USB cables included
• Exclusive LED illumination light - designed by ATEN to illuminate the keyboard and touchpad to allow visibility in low-light conditions
• Integrated KVM console with 19" LED-backlit LCD panel
• A single console controls up to 128 computers by cascading to 2 levels and connecting up to 8 switches
• USB or PS/2 keyboard and mouse emulation – computers boot even when the console focus is elsewhere
With limited server room space and rising maintenance costs, network administrators are now more than ever looking for solutions that reduce both costs and space requirements. ATEN LCD KVM switches offer a space saving, streamlined approach to KVM switching technology by integrating an LCD panel, full keyboard, and touchpad into a 1U rack-mountable sliding housing.
CL1308N LCD KVM switch features an integrated 19" LED-backlit LCD panel allowing access and control with up to 8 computers from a single console (keyboard, mouse, and monitor). As many as 8 additional switches can be cascaded bringing the total number of connected computers to 128 computers that can be controlled from a single keyboard-monitor-mouse console.
Setup is fast and easy - plugging cables into their appropriate ports is all that is needed. The switch supports both USB and PS/2 connections for the computers. CL1308N intercepts keyboard input directly, thus eliminating the need for any software configuration.
Switching between computers can be easily accomplished either by manually pressing the front panel push button port LEDs, entering hotkey combinations from the keyboard, or via a menu driven multilingual on-screen display (OSD) system.
A convenient auto-scan feature permits automatic scanning and monitoring of activities on all connected computers.
Features and Benefits
• Dual interface – supports computers with PS/2 or USB keyboards and mice
• Multiplatform support – Windows 2000/XP/Vista, Linux, Mac, and Sun
• Supports USB keyboards for PC, Mac and Sun
• Auto PS/2 and USB interface detection
• Superior video quality – up to 1280x1024 @ 75Hz; DDC2B
• Convenient computer switching via front panel push buttons, hotkeys, or multilingual on-screen display (OSD) menu
• Two level password security - only authorized users view and control computers; up to four users and an administrator with a separate profile for each
• Auto scan feature for monitoring user-selected computers
• Broadcast mode – operations simultaneously performed on all selected computers
• Hot pluggable – add or remove computers without having to power down the switch
• Buzzer on/off via hotkey and OSD
• Rack mountable
• Keyboard language supports English (US), English (UK), French, German, German (Swiss), Greek, Hungarian, Italian, Japanese, Korean, Russian, Spanish, Swedish and Traditional Chinese
Package Content
1x CL1308 LCD KVM switch with rack-mount kit
8x Custom KVM cables (VGA, USB; 6 feet) (see listing below for additional available cables)
1x Firmware upgrade cable
1x Power cord
1x User instructions
