Isolated DC Voltage Sensor, 40 feet

Model No. IDCV40 Ships within two weeks or less

Isolated DC Voltage Sensor, 40 feet
Buy this item and earn 184 ClubPoints.

IDCV40: An isolated digital voltmeter

can be used by OEMs and engineers to create their own custom data collection systems


The user can input a DC voltage range from -60 to 0 volts or 0 to 60 volts.

The sensor includes an isolated ground for better safety and protection against over voltages and shorts. Readings are available in both an absolute value and a percentage of full scale. Full scale is user programmable with both the base and top voltage from -60 to 0, or 0 to 60 volts.

AKCP's isolated digital voltmeter has the full range of functionality including SNMP integration, email and trap generation upon settable limits and thresholds.

The web interface for AKCP's isolated digital voltmeter is designed to simplify the settings when used with the external sensor. The unit of a measured entity can be customized to any text (e.g. lbs) for measuring the pressure. All numbers are now in a decimal point format, hence, it is possible to enter 12.8 Volts or 75.7 lbs in threshold settings, for example.

The isolation feature allows for the measurement at any point in a system with the possibility of sorting out problems such as the measurement of battery voltages in a string of batteries.

Integrate third party sensor into sensorProbe or securityProbe base units such as pressure transducers, solar power monitors, battery monitors and laboratory test equipment.

AKCP's isolated digital voltmeter allows the user to integrate a custom sensor to the sensorProbe or securityProbe while still retaining all of the features of the standard sensor. AKCP's isolated digital voltmeter sensor can provide real time data from the world around them. AKCP's isolated digital voltmeter can be used by OEMs and engineers to create their own custom data collection systems. Customers have added pressure transducers, solar power monitors, battery monitors, have integrated the sensorProbe and securityProbe into laboratory test equipment, and many other uses.

Features and Benefits
• Easy setup and installation
• Web browser interface available
• Create custom data collection systems
• Powered by securityProbe, no additional power required
• The unit of a measured entity can be customized to any text, e.g. Lbs for measuring the pressure
• Send advanced alerts from the securityProbe or AKCPro Server based upon set thresholds
• Send SNMP traps and or email alerts from sensorProbe units based upon set thresholds
• SNMP interface for alarm/normal status
• SNMP traps sent when status changes
• SNMP polling via GET is available
• When an alarm condition is activated, the description and location of the fault can be sent via email
• Cable length can be extended with a self-provided standard CAT-5/6 cable up to 60 feet
• Components manufactured using highly integrated, low power surface mount technology to ensure long term reliability
