12116: Metered, standard PDU, 20A, 120V or 208V, rack-mount, 16x IEC C13 receptacles

on/off switch, breakered, with IEC 60320 C20 inlet (no cord), local current monitoring, black powder coat finish

Improve reliability, energy efficiency, and prevent crippling downtime caused by overloads using Geist's metered PDU. Equipped with a local digital display, this metered PDU provides power consumption metrics instantly, ideal for when deploying or moving critical server equipment.

Without built-in surge protection, BREA160-0020/16 is equipped with a local digital current meter that provides real-time local load monitoring and helps to avoid potential overloads.

This metered PDU is ideal for installations in facilities with proper surge protection at the main electrical service entrance.

Monitoring: Current; local; aggregate - total unit monitoring; digital RMS current meter +/- 2% accuracy with full scale 60Hz sine wave input.

Plug                                            Receptacles

IEC 60320 C20 Inlet (no cord)      16x IEC C13 (12x rear; 4x face)

• Local display
• Horizontal, 19" rack-mount form factor
• Volts: 120V or 208V
• Amps: 20A
• kW-input: 1.9 or 3.3kW
• No cord
• Circuit breaker: Yes
• On/off switch: Yes
