2x1:4 4K Ultra-HD HDMI and HDBaseT splitter (distribution amplifier)
• Inputs: 1x HDBaseT; 1x HDMI
• Outputs: 4x HDBaseT; 1x HDMI
• Resolution Support up to 4K @ 60Hz (4:2:0) Ultra-HD
• Size: 19" (1U); Rack "ears" included
• Audio - U/E
VM-212DT is a 4K Ultra-HD looping distribution amplifier for HDMI and HDBaseT signals. It accepts one local HDMI input and one extended HDBaseT input, allows switching between the two, reclocks and equalizes the signal and distributes the selected signal to four identical HDBaseT outputs and a looping HDMI input.
It supports resolutions up to 4K @ 60Hz (4:2:0) Ultra-HD.
This product offers the versatility of control options and audio de-embedding.
Features and Benefits
• Resolution Support - Up to 4K @ 60Hz (4:2:0) Ultra-HD.
• Max. Data Rate - 10.2Gbps (3.4Gbps per graphic channel).
• HDTV Compatible.
• HDCP Compliant - Works with sources that support HDCP repeater mode.
• HDMI Support - Deep Color, x.v.Color™ and 3D.
• Automatic Live Input Detection - Based on video clock presence.
• Automatic Analog Audio Detection & De-embedding.
• Looping HDMI Output - Allow monitoring and cascading to additional DAs.
• I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling & processing algorithm ensures Plug and Play operation for HDMI systems.
• System Range - Up to 130m (430ft) at normal mode (2K), up to 100m at normal mode (4K); up to 180m (590ft) ultra mode (1080p @60Hz @24bpp) when using BC-HDKat6a cables.
• Data Equalization and Reclocking.
• Support for Digital Audio Formats.
• Lockable EDID and Default EDID - For fast and efficient connection of the unit.
• Support for EDID Designer.
• Size - Standard 19" (1U). Rack "ears" included.
Applications
• Presentation and multimedia applications
• Rental and staging
